Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Ohjausmenetelmä:Solenoidi

Jakaja:1 kela

Nimellisvirtaus:45 L/min (11,8 US gpm)

Maksimipaine:315 baaria (4 600 psi)

Tuloportti:G3/8

Ulostuloportti:G3/8

Liitäntäkoko:G3/8

Tuotemerkki:BXHS

Tuotetyyppi:Monolohkoinen suuntaventtiili

Tuotesarja:SD5-sarja Monolohkoinen suuntaventtiili

Pakkauskoko:30*13*13

Bruttopaino:5.40 kg

Saatavuus: Varastossa

1132 Näkymät etsivät tätä tuotetta

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable drawing image

The SD5 Series Log Splitter Spool Valve Solenoid Hydraulic Valve is a durable and reliable valve designed for use in a variety of applications, including material handling, construction, agriculture, and industrial vehicles. This monoblock valve features a solenoid control method, 1 section, 40 L/min rated flow, and 305 bar maximum pressure. It's available directly from the factory and can be customized to meet your specific needs.

SD5-sarja Monolohkoinen suuntaventtiili Parametrit
Ohjausmenetelmä Manuaalinen, Pneumattinen, Elektropneumaattinen, Elektrohydraulinen, Solenoidi, Hydraulinen, Hydraulinen ja Manuaalinen, Kaapeli, Ohjaussauva
Jakaja 1 kela, 2 kelaa, 3 kelaa, 4 kelaa, 5 kelaa, 6 kelaa, 7 kelaa
Ympäristön lämpötila-alue -40 °C - +60 °C (-40 °F - +140 °F)
Rakennetyyppi Yhdistelmäventtiili
Jakso 1 jakso, 2 jakso, 3 jakso, 4 jakso, 5 jakso, 6 jakso, 7 jakso
Käyttöviskositeettialue 15 - 75 mm²/s (15 cSt - 75 cSt)
Nimellisvirtaus 40 L/min (10,5 US gpm)
Maksimipaine 305 baaria (4 400 psi)
Tuloportti G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
Ulostuloportti G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
Liitäntäkoko G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

The SD5 Series Log Splitter Spool Valve Solenoid Hydraulic Valve is a high-performance, heavy-duty valve designed for use in demanding applications. It features a compact design, robust construction, and reliable performance. This monoblock valve is controlled by a solenoid, offering precise and responsive operation. The valve is available in a variety of configurations to meet your specific needs. It is also available with a range of options and accessories, including custom-engineered solutions. The SD5 Series is the perfect choice for a wide range of applications including material handling, construction, agriculture, and industrial vehicles. It is also suitable for use in a variety of harsh environments. Contact us today to learn more about this high-quality hydraulic valve.
