P40-G12-G38-OT 2-Spool Directional Valve | Factory Direct & Customizable

Ohjausmenetelmä:Manuaalinen

Jakaja:2 kelaa

Nimellisvirtaus:40 L/min (10,5 US gpm)

Maksimipaine:250 baaria (3 600 psi)

Tuloportti:G1/2

Ulostuloportti:G1/2

Liitäntäkoko:G3/8

Tuotemerkki:BXHS

Tuotetyyppi:Monolohkoinen suuntaventtiili

Tuotesarja:P40-sarja Monolohkoinen suuntaventtiili

Pakkauskoko:23*18*13

Bruttopaino:5.50 kg

Saatavuus: Varastossa

1061 Näkymät etsivät tätä tuotetta

P40-G12-G38-OT 2-Spool Directional Valve | Factory Direct & Customizable

P40-G12-G38-OT 2-Spool Directional Valve | Factory Direct & Customizable

P40-G12-G38-OT 2-Spool Directional Valve | Factory Direct & Customizable drawing image

The Steering Unit P40-G12-G38-OT 2-Spool Directional Valve is a robust and reliable hydraulic valve designed for a variety of applications in material handling, construction, agriculture, and industrial vehicles. This monoblock valve features manual control, a 40 L/min rated flow, and a maximum pressure of 250 bar, making it suitable for demanding operating conditions. Available for factory direct purchase and customization, this valve is perfect for OEM and ODM needs.

P40-sarja Monolohkoinen suuntaventtiili Parametrit
Ohjausmenetelmä Manuaalinen, Pneumattinen, Elektropneumaattinen, Elektrohydraulinen, Solenoidi, Hydraulinen, Hydraulinen ja Manuaalinen, Kaapeli, Ohjaussauva, Solenoidi ja ohjaussauva, Ohjaussauva ja manuaalinen, Solenoidi ja kaapeli
Jakaja 1 kela, 2 kelaa, 3 kelaa, 4 kelaa, 5 kelaa, 6 kelaa, 7 kelaa
Ympäristön lämpötila-alue -40 °C - +80 °C (-40 °F - +176 °F)
Rakennetyyppi Yhdistelmäventtiili
Jakso 1 jakso, 2 jakso, 3 jakso, 4 jakso, 5 jakso, 6 jakso, 7 jakso
Käyttöviskositeettialue 15 - 75 mm²/s (15 cSt - 75 cSt)
Nimellisvirtaus 40 L/min (10,5 US gpm)
Maksimipaine 250 baaria (3 600 psi)
Tuloportti G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ulostuloportti G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Liitäntäkoko G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-G38-OT 2-Spool Directional Valve is a high-performance hydraulic component designed for precise steering control in various applications. This 2-section monoblock valve features a manual control method, providing operators with direct control over the steering system. With a rated flow of 40 L/min and a maximum pressure of 250 bar, the valve is capable of handling demanding workloads. Its wide operating viscosity range of 15 - 75 mm²/s ensures optimal performance across different operating temperatures. The valve's durable construction and robust design allow it to withstand harsh environments and demanding operating conditions. The P40 Series valve is ideal for use in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, and other industrial vehicles. This versatile valve is available for factory direct purchase and offers customization options to meet specific requirements. As a manufacturer, we provide OEM and ODM services, offering wholesale pricing for bulk orders. We are actively seeking distributors, wholesalers, agents, and traders to expand our global reach.
