Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump

Iskutilavuus:63 cm³/kierros

Nimellispaine:20 MPa (2900 psi)

Maksimipaine:25 MPa (3625 psi)

Maksiminopeus:2500 r/min

Pyörimissuunta:Kaksisuuntainen

Tuotemerkki:BXHS

Tuotetyyppi:Hydraulinen hammaspyöräpumppu

Tuotesarja:CBHC-sarja Hydraulinen hammaspyöräpumppu

Pakkauskoko:34*18*18

Bruttopaino:15.00 kg

Saatavuus: Varastossa

222 Näkymät etsivät tätä tuotetta

Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump

Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump

Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump drawing image

This CBHC-2063 Hydraulic Gear Pump features 63 cc/rev displacement, 20 MPa rated pressure, and bidirectional rotation, ideal for forklifts and loaders. Backed by a Professional Manufacturer with 25+ years of experience and IATF 16949 certification, it ensures reliable performance for heavy-duty applications.

CBHC-sarja Hydraulinen hammaspyöräpumppu Parametrit
Iskutilavuus 32 cm³/kierros, 40 cm³/kierros, 50 cm³/kierros, 63 cm³/kierros, 80 cm³/kierros, 100 cm³/kierros, 25 cm³/kierros, 110 cm³/kierros
Nimellispaine 20 MPa (2900 psi), 22 MPa (3190 psi)
Maksimipaine 25 MPa (3625 psi), 28 MPa (4061 psi)
Nimellisnopeus 2200 r/min
Maksiminopeus 2500 r/min
Pyörimissuunta Vasen (vastapäivään), Oikea (myötäpäivään), Kaksisuuntainen
Materiaali Valurauta
Rakenne Ulkohampainen hammaspyöräpumppu
Laippaversio SAE-laippa
Akselityyppi H: Suorakaiteen muotoinen ura

**1. High-Efficiency Hydraulic Gear Pump Specifications**
- Delivers consistent flow with 63 cc/rev displacement, operating at rated pressure of 20 MPa (2900 psi) and max pressure of 25 MPa.
- Supports bidirectional rotation with max speed up to 2500 r/min, ensuring versatile integration into complex hydraulic systems.

**2. Versatile CBHC Series Gear Pump Applications**
- Engineered for Material Handling and Construction sectors, perfectly compatible with Forklifts, Telehandlers, Skid Steer Loaders, and Mini-Excavators.
- Designed as a direct replacement for international brands, offering seamless fitment for Wheel Loaders and Backhoe Loaders without system modification.

**3. Reliable 63cc Hydraulic Pump Quality Control**
- Manufactured in our 68,000㎡ facility with 260+ CNC machines, every unit undergoes 100% bench testing for pressure, flow, and sealing integrity.
- Certified under IATF 16949 and CE standards, with SGS detection and 25+ patents guaranteeing zero-defect delivery for critical industrial vehicles.

**4. Customizable OEM Hydraulic Gear Pump Solutions**
- Supported by 35+ senior engineers, we offer full OEM/ODM services including custom castings, logo laser marking, and private label packaging.
- Flexible customization allows distributors to create unique product lines while maintaining the high durability expected from a Wholesale China Factory.

**5. Factory Direct Sales & Global Logistics**
- Benefit from Factory Direct Sales pricing with an annual capacity of 1,500,000 units, ensuring stable supply for large-scale wholesale orders.
- Products are secured with anti-rust treatment and heavy-duty wooden crates, supporting Exported Worldwide logistics with fast lead times for urgent projects.
