Our factory-assured DCV40 valves guarantee top-notch quality for your hydraulic system needs. These valves feature precise pneumatic control, a compact monoblock design, and exceptional performance parameters: 40 L/min rated flow, 350 bar max pressure, and a wide operating viscosity range. They are suitable for diverse applications in material handling, construction, earth moving, agriculture, and industrial vehicles.
| DCV40-sarja Monolohkoinen suuntaventtiili Parametrit | |
|---|---|
| Ohjausmenetelmä | Manuaalinen, Pneumattinen, Elektropneumaattinen, Elektrohydraulinen, Solenoidi, Hydraulinen, Hydraulinen ja Manuaalinen, Kaapeli, Ohjaussauva, Solenoid och käsikäyttö, Ohjaussauva ja manuaalinen |
| Jakaja | 1 kela, 2 kelaa, 3 kelaa, 4 kelaa, 5 kelaa, 6 kelaa, 7 kelaa |
| Nimellisvirtaus | 40 L/min (10,5 US gpm) |
| Maksimipaine | 350 baaria (5 100 psi) |
| Tuloportti | G3/8, G1/2, SAE 8, SAE 14, 3/8 NPT, 1/2 NPT |
| Ulostuloportti | G1/2, M18×1.5, M22×1.5, SAE 8, SAE 14, 1/2 NPT |
| Liitäntäkoko | G1/2, M18×1.5, M22×1.5, SAE 8, SAE 14, 3/8 NPT, 1/2 NPT |
| Jakso | 1 jakso, 2 jakso, 3 jakso, 4 jakso, 5 jakso, 6 jakso, 7 jakso |
| Rakennetyyppi | Yhdistelmäventtiili |
| Ympäristön lämpötila-alue | -40 °C - +80 °C (-40 °F - +176 °F) |
| Käyttöviskositeettialue | 15 - 75 mm²/s (15 cSt - 75 cSt) |
**DCV40 Series Valves: Factory Assurance, Precision Performance**
Manufactured and factory-supplied, our DCV40 series valves deliver reliable and efficient fluid control. These valves are meticulously crafted as monoblock units, ensuring structural integrity and minimizing potential leak points. Their pneumatic control mechanism provides precise and responsive operation. With a rated flow of 40 L/min and a maximum pressure of 350 bar, they can handle demanding hydraulic systems effectively. The operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) makes them suitable for various fluids. The valves are designed to perform consistently in a wide ambient temperature range of -40°C to +80°C (-40°F to +176°F). They feature two spools, allowing for versatile flow control in your hydraulic system.
Our DCV40 valves find applications in a wide range of industries, including material handling, construction, earth moving, agriculture, and industrial vehicles. They are ideally suited for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. By choosing our factory-assured DCV40 valves, you can ensure the optimal performance and reliability of your hydraulic systems.
