Customizable Solenoid Directional Valve | Made to Your Specifications

Ohjausmenetelmä:Solenoidi

Jakaja:9 kelaa

Nimellisvirtaus:60 L/min (15,8 US gpm)

Maksimipaine:315 baaria (4 600 psi)

Tuloportti:G1/2

Ulostuloportti:G1/2

Liitäntäkoko:G1/2

Tuotemerkki:BXHS

Tuotetyyppi:Suuntaventtiili

Tuotesarja:DCV58-sarja Suuntaventtiili

Pakkauskoko:55*28*17

Bruttopaino:33.00 kg

Saatavuus: Varastossa

1070 Näkymät etsivät tätä tuotetta

Customizable Solenoid Directional Valve | Made to Your Specifications

Customizable Solenoid Directional Valve | Made to Your Specifications

Customizable Solenoid Directional Valve | Made to Your Specifications drawing image

This is a high-performance, customizable hydraulic motor valve designed for demanding industrial applications. It features a 9-section, solenoid-controlled design, high flow rate (60 L/min), and high pressure rating (350 bar). Ideal for material handling, construction, agriculture, and industrial vehicles.

DCV58-sarja Suuntaventtiili Parametrit
Ohjausmenetelmä Solenoidi, Solenoid och käsikäyttö
Jakaja 1 kela, 2 kelaa, 3 kelaa, 4 kelaa, 5 kelaa, 6 kelaa, 7 kelaa, 8 kelaa, 9 kelaa, 10 kelaa, 11 kelaa, 12 kelaa
Ympäristön lämpötila-alue -40 °C - +80 °C (-40 °F - +176 °F)
Rakennetyyppi Jaksoventtiili
Jakso 1 jakso, 2 jakso, 3 jakso, 4 jakso, 5 jakso, 6 jakso, 7 jakso, 8 jakso, 9 jakso, 10 jakso, 11 jakso, 12 jakso
Käyttöviskositeettialue 15 - 75 mm²/s (15 cSt - 75 cSt)
Nimellisvirtaus 40 L/min (10,5 US gpm)
Maksimipaine 350 baaria (5 100 psi)
Tuloportti G1/2, M22×1.5, SAE 10, 1/2 NPT
Ulostuloportti G1/2, M22×1.5, SAE 10, 1/2 NPT
Liitäntäkoko G1/2, M22×1.5, SAE 10, 1/2 NPT

This versatile **hydraulic motor valve** is a **customizable, high-performance** solution for your industrial needs. The **9-section, solenoid-controlled** design provides precise and reliable operation in a wide range of applications. With a **rated flow of 60 L/min** and a **maximum pressure of 350 bar**, this valve is capable of handling demanding workloads. The **sectional valve** construction allows for easy maintenance and repair. Designed for **heavy-duty operation**, it operates within a broad temperature range (-40°C to +80°C). Suitable for use in **material handling**, **construction and earth moving**, **agriculture**, and **industrial vehicles** such as **telehandlers**, **forklifts**, **all terrain cranes**, **stackers**, **aerial platforms**, **motor graders**, **midi-excavators**, **mini-excavators**, **skid steer loaders**, and **compact wheel loaders**. Part of the **DCV58 Series**, this valve is built to meet the highest industry standards.
